Stockist & supplier API 5L · IS 3589 · ASTM A671 · ASTM A672
LSAW Pipes — Large Diameter, API 5L & IS 3589
LSAW pipe is large-diameter steel pipe made from plate and joined by a straight submerged-arc weld. Teshi Group supplies LSAW pipe to API 5L, IS 3589 and ASTM A671/A672 for transmission, process and structural use, sourced from pipe mills. Quotes are sent in 24–48 hours.
Also called: longitudinal submerged arc welded pipe, SAWL pipe, large diameter welded pipe, DSAW pipe
What is an LSAW Pipe?
Longitudinal submerged arc welded (LSAW) pipe is formed from a single steel plate, bent into a cylinder (for example by the JCOE or UOE process) and welded along its length by submerged arc welding, normally from inside and outside. Because it is made from plate, LSAW pipe can be produced in heavy walls and large diameters with good dimensional control. It is chosen for high-pressure oil and gas trunk lines, offshore and onshore pipelines, large process headers and structural piling where ERW sizes run out.
Key features
- Stockist and supplier — sourced from LSAW mills; Teshi does not manufacture pipe
- Straight single seam made by submerged arc welding
- Suited to heavy walls and large diameters
- Grades from API 5L Gr B to X-grades, and plate-pipe grades to ASTM A671/A672
- Bevelled ends for field welding; coating as ordered
- Supplied with Teshi-manufactured large-diameter flanges (ASME B16.47) when required
Specification
| Supply | Stockist & supplier — Teshi Group, India, India |
|---|---|
| Standards | API 5L (SAWL, PSL1 / PSL2), IS 3589, ASTM A671 / A672 (EFW plate pipe) |
| Size range | Large diameters, typically NPS 16″ and above; exact OD and wall against order |
| Grades | API 5L Gr B, X42–X70; IS 3589 Fe 410; A671/A672 plate grades such as A516 Gr 60/70 |
| Weld | Longitudinal submerged arc weld, inside and outside |
| Ends | Bevelled for butt welding, or plain end |
| Coating | Bare, primer, 3LPE/FBE or other coatings as ordered |
| Testing | Hydrostatic test, weld-seam UT/RT and other tests per the standard and order |
| Documents | Mill test certificate to EN 10204 3.1; EN 10204 3.2 / third-party inspection when the order specifies |
Applications
- Oil and gas transmission pipelines
- Water transmission and penstock lines
- Large process and cooling-water headers
- Structural piling and jetty piles
- Slurry and ash handling lines in power plants
Material grades
All gradesFAQ
LSAW Pipe: common questions
What is the difference between LSAW and HSAW pipe?
LSAW has a straight longitudinal seam made from one plate; HSAW (spiral) has a helical seam made from coil. LSAW is generally preferred for high-pressure and heavy-wall service, while HSAW is economical for large-diameter water and low-pressure lines.
What is the difference between LSAW and ERW pipe?
ERW uses electric-resistance welding without filler metal and is made from coil in smaller sizes. LSAW uses submerged arc welding with filler wire, is made from plate, and covers larger diameters and heavier walls.
Do you supply ASTM A672 pipe?
Yes, against order. ASTM A672 covers electric-fusion-welded pipe made from pressure-vessel plate, often A516 Gr 60 or 70, for high-pressure service at moderate temperatures. State the class (heat treatment and testing) in your enquiry.
Does Teshi manufacture LSAW pipe?
No. Teshi Group is a stockist and supplier of LSAW Pipe, sourced from established mills and supplied with the original mill test certificate. Teshi is an OEM manufacturer of flanges, fittings, fasteners, valves and custom fabrications, which can be ordered with it.
Need a size or grade not listed here?
We source against your specification from approved mills, with mill test certificates and inspection before dispatch.
Send us your specificationTraceability
From mill heat to your site
- 01
Approved mill material
Received against the mill certificate; heat number registered.
- 02
Forging & machining
Heat number carried through every stage in our Indian works.
- 03
PMI, dimensional & NDT
Every lot inspected to the governing standard; TPI witness on request.
- 04
Stamped & certified dispatch
Hard-stamped pieces with EN 10204 3.1 / 3.2 certificates.
Quick RFQ
Quote for LSAW Pipe in 24–48 hours
