Teshi Group: Leading Manufacturer, Stockist, Supplier, and Exporter of Outlet Flanges in India.
Teshi Group is a leading manufacturer, stockist, supplier, and exporter of high-quality outlet flanges in India, renowned for its commitment to excellence and innovation in the field of industrial fittings. With decades of experience and a reputation for delivering precision-engineered products, Teshi Group offers a wide range of outlet flanges designed to meet the diverse needs of various industries. These flanges are crucial components in piping systems, providing secure connections for branch lines and ensuring the reliable flow of fluids and gases under high pressure and temperature conditions. Teshi Group manufactures outlet flanges using the finest materials such as stainless steel, carbon steel, alloy steel, and more, ensuring superior strength, durability, and corrosion resistance. The company adheres to international standards and utilizes advanced technology to produce flanges that meet rigorous quality checks and industry specifications. Whether for use in the oil and gas, chemical, petrochemical, pharmaceutical, or power generation sectors, Teshi Group’s outlet flanges are engineered to provide optimal performance and safety. As both a supplier and exporter, Teshi Group has built a solid global presence, catering to clients in countries around the world with its reliable and timely delivery. Their dedication to customer satisfaction and quality assurance has made them a trusted name in the manufacturing and supply of outlet flanges, solidifying their position as an industry leader in India and beyond.
Teshi Group is an ISO certified Outlet flange manufacturer & distributor in India.
About Outlet Flanges :-
Outlet Flanges are specialized flanges designed for use in piping systems to create a branch connection from a larger pipeline. These flanges are typically used to connect a smaller pipe to a larger one, allowing fluid or gas to be diverted to another part of the system. Outlet flanges are often used in applications where there is a need for multiple branch connections, such as in distribution networks, process lines, and systems requiring precise fluid control.
The design of an Outlet Flange includes a hole or opening, which is aligned with the branch pipe to facilitate the connection. These flanges can be customized with various sizes and configurations, depending on the application’s requirements. The most common types of outlet flanges are Nipoflange (or Weldo flange) and Buttweld Outlet Flanges, where a pipe is directly welded to the flange body, providing a secure and leak-resistant connection.
Outlet flanges are widely used in industries like oil and gas, water treatment, chemical processing, and power generation. They are designed to withstand high pressures and temperatures, and can be made from materials such as carbon steel, stainless steel, and alloy steels, ensuring compatibility with various operational conditions, including corrosive environments and extreme operating temperatures.
Manufactured to meet industry standards like ASME B16.5, ANSI, and API, Outlet Flanges ensure high-quality and reliable connections for pipeline systems. Their robust construction and versatility in material selection make them essential components in systems where fluid needs to be diverted to multiple pathways. They offer a cost-effective solution for branching systems, simplifying the installation process and ensuring long-term performance and reliability.
Dimensions of Outlet Flanges
Standard Specification of Outlet Flange
Standard Specifications |
Dimensions
|
ANSI B16.5, ANSI B16.47 Series A & B, MSS SP44, ASA, API-605, AWWA, Custom Drawings
|
|---|---|
|
Size
|
1/2" (15 NB) to 48" (1200NB)
|
|
Class
|
150 LBS, 300 LBS, 600 LBS, 900 LBS, 1500 LBS, 2500 LBS, DIN Standard ND-6,10, 16, 25, 40 Etc.
|
|
DIN
|
DIN 2527, DIN 2566, DIN 2573, DIN 2576, DIN 2641, DIN 2642, DIN 2655, DIN 2656, DIN 2627, DIN 2628, DIN 2629, DIN 2631, DIN 2632, DIN 2633, DIN 2634, DIN 2635, DIN 2636,DIN 2637, DIN 2638, DIN 2673
|
|
BS
|
BS 4504 , BS 4504, BS 1560, BS 10
|
|
PN
|
PN6, PN10, PN16, PN25, PN40
|
|
Flange Face Type
|
Flate Face (FF), Raised Face (RF), Ring Type Joint (RTJ)
|
Material & Grades of Outlet Flange
Material & Grades |
Stainless Steel Outlet Flange
|
ASTM A 182, A 240 F 304, 304L, 304H, 316, 316L, 316Ti, 310, 310S, 321, 321H, 317, 347, 347H, 904L
|
|---|---|
|
Duplex & Super Duplex Steel Outlet Flange
|
ASTM / ASME A/SA 182 F 44, F 45, F51, F 53, F 55, F 60, F 61
|
|
Carbon Steel Outlet Flanges
|
ASTM / ASME A/SA 105 ASTM / ASME A 350, ASTM A 181 LF 2 / A516 Gr.70 A36, A694 F42, F46, F52, F60, F65, F706
|
|
Low Temperature Carbon Steel Outlet Flanges
|
ASTM A350, LF2, and LF3
|
|
Alloy Steel Outlet Flanges
|
ASTM / ASME A/SA 182 & A 387 F1, F5, F9, F11, F12, F22, F91
|
|
Copper Alloy Steel Outlet Flanges
|
ASTM SB 61 , SB62 , SB151 , SB152 UNS No. C 70600 (Cu-Ni 90/10), C 71500 (Cu-Ni 70/30), UNS No. C 10100, 10200, 10300, 10800, 12000, 12200
|
|
Nickel Alloy Outlet Flanges
|
ASTM SB564, SB160, SB472, SB162 Nickel 200 (UNS No. N02200), Nickel 201 (UNS No. N02201), Monel 400 (UNS No. N04400), Monel 500 (UNS No. N05500), Inconel 800 (UNS No. N08800), Inconel 825 (UNS No. N08825), Inconel 600 (UNS No. N06600), Inconel 625 (UNS No. N06625), Inconel 601 (UNS No. N06601), Hastelloy C 276 (UNS No. N10276), Alloy 20 (UNS No. N08020)
|
Application Of Outlet Flange
Sl |
Application |
1
|
ANSI B16.5 Class 150 Outlet Flange uses in Industrial Boilers Industry
|
|---|---|
|
2
|
ASTM A182 Stainless Steel Outlet Flange uses in Power Plants Industry
|
|
3
|
ASME B16.47 Series A and B Outlet Flange uses in Nuclear Plants Industry
|
|
4
|
Stainless Steel Outlet Flange uses in Oil & Gas Industry
|
|
5
|
Super Duplex Steel Outlet Flange uses in Refineries Industry
|
|
6
|
Industrial Outlet Flange uses in Ship Building Industry
|
|
7
|
Super Duplex Steel Outlet Flangea Forged Flange uses in Heat Exchanger Industry
|
|
8
|
Carbon Steel Industrial Outlet Flange uses in Condensers Industry
|
|
9
|
Alloy Steel Industrial Outlet Flange uses in Paper & Pulp Industry
|
|
10
|
Duplex Steel Industrial Outlet Flange uses in Marine Applications
|
|
11
|
Stainless Steel Industrial Outlet Flange uses in Nuclear Power Industry
|
|
12
|
Industrial Outlet Flangea / Fittings System uses in Fossil Fuel Power Plants Industry
|
