MACHINERY
We use world-class precision machinery to produce flawless products with no compromises in quality.
Machinery We Use
CNC LATHE MACHINE
A CNC lathe machine is normally used to perform / produce precise round shapes with both an Outer Diameter (OD), and an Inner Diameter (ID). Practically all kinds of structures could be machined with this machine tool, depending on their needs in different industries.
HORIZONTAL LATHE MACHINE
A horizontal lathe is a machine tool that mainly uses a turning tool to turn a rotating work piece. The main components are spindle box, exchange gearbox, feed box, slide box, tool holder, tail stock, smooth screw, lead screw, bed, bed foot, and cooling device.
FORGING HAMMER
Forging hammers are used in the drop forging to form the metal between two dies. The material is placed in the lower die and then hammered with the upper one until the hot metal flows in all directions, filling the die cavity.
MOULDS
Function-used to pushing elbow, expanding pipe, producing of Reducer, Caps, Punch of Elbow halves, Correcting of pipe fittings
Material: 2520, 2014, 304, 45# steel, 40# steel, 35# steel.
HYDRAULIC MACHINE
Professional equipment for the forming of pipe fittings, correction of pipe fittings, clamping, bending and metal punching.
Specifications-
1. Grades: 500 tons, 1000 tons, 2000 tons, 2500 tons, 3000 tons.
2. Construction types: Columns, frames
3. Material: carbon steel, alloy steel, stainless steel
Accessories for the progress-
1. Moulds.
2. Hydraulic Oil.
COLD DRAW TEE MACHINE
Professional equipment used to producing Tee
Specifications-
1. Production Range: OD 21mm-2100m
2. Thickness: Max. 50 mm
3. Material: Carbon Steel, Alloy Steel
4. Drive Type: Hydraulic
Accessories for the progress-
1. Moulds.
2. Calibration Machine.
3. Bevel Machine.
HYDRAULIC BENDING MACHINE
Hydraulic bending machine is generally used in the industry for the bending of plates, and the strength is controlled according to the system parameters to achieve different bending effects. The structure includes a support, a workbench, and a clamping plate. The workbench is composed of a base and a pressing plate.
PIPE BENDING MACHINE
Professional equipment used to manufacture 180-degree bends (pipe fittings), shape steel and Rail bends.
Specifications-
1. Production Range: OD 21mm – 1420mm
2. Radius: 2.5D – 100D
3. Thickness: 10mm – 80mm
4. Material: Carbon Steel, Alloy Steel Stainless Steel
5. Drive Type: Hydraulic, Chain
Accessories for the progress-
1. Intermediate Frequency Power Source.
2. Heating Induction Coil.
3. Quenching Transformer.
4. Clamps.
ELBOW MACHINE
Specifications-
1. Production Range: OD 21mm-1420mm
2. Radius: 10,1.5D, 2D, 3D, 50,8D, 10D etc.
3. Thickness: 3mm -100mm
4. Material: Carbon Steel, Alloy Steel, etc.
5. Drive Type: Hydraulic, Chain
Accessories for the progress-
1. Intermediate Frequency Power Source.
2. Heating Induction Coil.
3. Mandrels.
4. Hydraulic Press.
5. Bevel Machine.
| wdt_ID | SL.NO. | MACHINES | NUMBER OF MACHINES |
|---|---|---|---|
| 1 | 1 | Oil Furnace suitable for 600 NB Pipe Bending | 1 |
| 2 | 2 | Drop Hammer with 2 MT Capacity | 2 |
| 3 | 3 | Drop Hammer with 750 Kg Capacity | 2 |
| 4 | 4 | Drop Hammer with 500 Kg Capacity | 1 |
| 5 | 5 | Hydraulic Press with 400 MT capacity | 2 |
| 6 | 6 | Hydraulic Press with 200 MT capacity | 1 |
| 7 | 7 | Power Press with 250 MT capacity | 1 |
| 8 | 8 | Chuck Lathe (Capacity 96” NB Flange Mfg.) | 2 |
| 9 | 9 | Face Chuck (Capacity 72” NB Flange Mfg.) | 4 |
| 10 | 10 | Face Chuck (Capacity 44” NB Flange Mfg.) | 8 |
| 11 | 11 | Lathe Machine – 12’ 6” (Capacity 32” NB Flange Mfg.) | 8 |
| 12 | 12 | Lathe Machine – 8’ 6” (Capacity 20” NB Flange Mfg.) | 10 |
| 13 | 13 | Lathe Machine – 6’ 6” (Capacity 16” NB Flange Mfg.) | 8 |
| 14 | 14 | Radial Drill Machine – 2” Capacity | 4 |
| 15 | 15 | Drill Machine – 2” Capacity | 6 |
| 16 | 16 | Drill Machine – 1½” Capacity | 8 |
| 17 | 17 | Gas Cutting Set | 12 |
| 18 | 18 | Welding Set | 6 |
| 19 | 19 | Grinding Set | 8 |
| 20 | 20 | Hand Grinder | 4 |
| 21 | 21 | Generator 62 KVA | 1 |
